Filter Press Spare Parts:

  • Filter Plates
  • Filter Cloth
  • Hydraulic Station
  • Pressure gauge
  • Hydraulve valves.
Product Details

Introduction to Filter Press Spare Part:

The spare parts of the filter press are filter cloth, filter plates, filter plate handles, filter press nozzles, etc. We can make the size of the filter cloth and filter plates according to the requirements.
We use German machines for the filter plates, etc.; this makes sure are smooth and flat. Also, for the filter fabric, we will use heat treatment before delivery to make sure it will not be out of shape when used.

Main Spare Parts :

Filter cloth:  Filter cloth is a filter medium woven from natural or synthetic fibers. It is a very important part of the filter press. Whether the filter press can work ideally depends largely on the performance of the filter cloth and whether it can achieve solid-liquid separation without clogging or damage.

Filter cloth can be divided into two categories according to the fiber material; one is a natural fiber, such as cotton, wool, silk, or hemp fiber; the other is a chemical synthetic fiber, such as polyester, nylon, vinylon, rayon, etc. The yarns that make up the filter cloth can be divided into monofilament, multifilament, and short fiber. We have filter fabric material of Polypropylene(PP), Polyester, Polyamide, Polyvinyl, and some special filter cloth such as aramid, PTFE, PVDF, etc.

The filter cloth made of monofilament is not easy to block and has a good cake-unloading performance. Multifilament yarn filter cloth is characterized by high tensile strength, good cake unloading performance, and regeneration performance. Short fiber yarn filter cloths feature good particle retention while providing excellent sealing properties. The filter cloth woven with monofilament yarn is called “monofilament fabric”; the filter cloth woven with multifilament or short fiber yarn is collectively called “multifilament fabric.”

filter cloth

Filter plates: A filter press plate is a component of a filter press machine used in solid-liquid separation processes. Filter plates are typically made of a variety of materials, such as polypropylene, stainless steel, cast iron, or aluminum. They come in different shapes and sizes depending on the application and filtration requirements. We can make cast iron plate and frame filter plates,304/316 stainless steel filter plates, PP filter plates, round filter plates, high-pressure filter plates that can bear 2.0 Mpa pressure, etc. We can make high-temperature filter plates and cloth acid-resistant filter plates and cloth.

filter plate

Parameters:

Filter cloth parameter

Common size of filter cloth for filter press
Filter press modelFilter plate modelFilter plate sizeCommon filter cloth size
model:XMY150/1250UB 1250Indicates the filter plate size;150Represents the filtered square number500 500x500mm550x550mm
630630x630mm700x700mm
800 800x800mm900x900mm
1000 1000x1000mm1100x1100mm
12501250x1250mm1350x1350mm
1500 1500x1500mm1600x1600mm
1600 1600x1600mm1700x1700mm
2000 2000x2000mm2100x2100mm

Filter plate parameter

ItemModelOutside Diameter(mm)Inner Diameter(mm)Volume(mm)Plate Thickness(mm)Side-hole Diameter(mm)Central-hole Diameter(mm)Central-hole Thickness(mm)Weight(kg)
Chamber32038032030453550114.5
45050545030504080278.5
6307056303050601001617
8008007253060601002427
8708708003055701001827
9009008203060601002039
100010009203060601202839
1250125011503065751503567
15001500139030708018045100
200020001860308510020040200
Plate & frame32038032030303513.5
45050543030305021.6
63071063030306542.5
89089079035356570
1000100090035356595.5
Membrane plate87087077065501005538
1000100089072601006050
12501250114078651207076
150015001380859018070115
Chamber plate(for membrane filter press)8708707703065501004038
100010008903070601004052
1250125011403575651204085
15001500138035809018040125
Cast iron1000100035
Round Plate800810558425

Production Workshop

filter cloth workshop

filter plate workshop

Customer Visiting

customer visiting

customer visiting

Packging&Shipping

packging delivery

Application

  1. Catalyst filtration and separation;
  2. Filtration of high-temperature gas in petrochemical industry, filtration of exhaust gas in petrochemical plants, filtration of catalytic cracking oil slurry;
  3. Purification of high-temperature flue gas in the metallurgical industry;
  4. Filtration of other high-temperature gases and liquids;
  5. Filtration of various high-temperature, corrosive liquids and catalysts in the petrochemical industry;
  6. Filtration and purification of various polymer melts in the chemical fiber film industry;
  7. Filtration and separation of various catalysts in the pharmaceutical industry;
  8. For gas distribution, orifice plate material for liquidized bed;
  9. Used for high-pressure backwashing oil filters, etc.;
  10. Used to filter various slurries of edible oil, beverage, and food;
  11. Used to purify and filter production sewage.
